Aeromotive Universal Brushless In-Tank Pump, 3.5gpm Spur Gear
Part Number 18374 Universal 3.5 Brushless Stealth Gear Pump
Pro-Series Performance Plus Advanced Technology
This configuration features a universal filter pickup, for an overall height adjustment from 10-16in.
EFI Rated flow of 1,250 lbs./hr. @ 40 psi, 13.5 volts
Carb Rated Flow of 1,350 lbs./hr. @ 9 psi, 13.5 volts
Pro-Series Performance Plus Advanced Technology
This configuration features a universal filter pickup, for an overall height adjustment from 10-16in.
- The Pro-Series performance you expect and more:
-
Fuel injected engines:
up to 2400 FWHP – naturally aspirated
up to 1800 FWHP – forced air induction -
Carbureted engines:
Up to 2600 FWHP – naturally aspirated
Up to 2000 FWHP – forced air induction
-
Fuel injected engines:
- E85 Compatible, reduce max FWHP by 30%
- Lighter than the traditional Pro-Series pump.
- Reduced current draw at higher, EFI pressures.
- Extended service life in methanol and ethanol.
- New integral spur-gear pumping mechanism.
- 90-PSI continuous operating pressure and up to 150-PSI peak pressure, base plus boost.
- Integral, external brushless controller for clean installation, cooler fuel and enhanced reliability.
- ORB-10 outlet port.
- Requires straight 12-VDC to 16-VDC power supply.
- Not compatible with pulse modulated systems or fuel pump speed controllers.
EFI Rated flow of 1,250 lbs./hr. @ 40 psi, 13.5 volts
Carb Rated Flow of 1,350 lbs./hr. @ 9 psi, 13.5 volts
